I-30l ye-accumulator blow umshini wokubumba wokubumba

Model:KGB80AP

I-KGB80AP ingumshini wokubumba ophindwe kabili wama-30l ohlanganisa ungqimba oluphindwe kabili noma umbala ophindwe kabili wombala wokubumba umklamo. Le mishini ingeyomikhiqizo yombala noma ilungele izinhlelo zokusebenza zemishini yokubumba e-Double

IVolumu: 30lIsisindo: 13t

Thumela Uphenyo

Incazelo Yomkhiqizo

Imodeli ejwayelekile ye-KGB80AP, hhayi nje kuphela umshini wokubumba ojwayelekile we-30l we-accumulator, kodwa futhi futhi uhlelo lokukhishwa okuphindwe kabili lungalingana nohlobo oluphindwe kabili noma izidingo zokukhiqizwa kombala eziphindwe kabili.
Kubandakanya isilawuli sokuqina kwe-moog 100, ingalo ye-robot, nokuvunguza okuphansi Uhlelo, ukuthuthukisa umkhiqizo kanye nekhwalithi yomkhiqizo. Lo mshini ohlukahlukene ilungele izicelo ezahlukahlukene, kufaka phakathi i-Chemical Drum Blow Ukubumba Izixazululo Zomshini, izinqubo zokukhishwa kweplastiki zokubumba ,.

Ukucacisa

inombolo yomkhiqizo	Indwangu PE, PP, ABS ...	Isilinda ka-Mold Ukuvala uwoyela (isilinda esisodwa)
inombolo yomkhiqizo	Indwangu PE, PP, ABS ...	Imodeli Yomshini: KGB80AP
Ukucacisa
1	Umthamo we-MAX	30 l
2	Okukhiphayo (umjikelezo owomile)	I-650 PC / hr
3	I-Machine Dimension (l × w × h × h)	4.7 m x3.5 m x 4 m
4	Isisindo somshini	I-13t
I-Clamping Unit
1	Amandla eCembang	215 k
2	Usayizi we-Mold Platen (w × h)	I-750 mm × 860 mm
3	Amapuleti okuvula ngaphandle kwempondo	I-350 mm -850 mm
4	Unhlangothi oluhamba kancane	370 mm
5	Ubukhulu be-Max Mold (w × h)	520 mm × 860 mm
6	Ubukhulu bokubumba	I-360 mm - 420 mm
Ubuqhwaga
1	Amandla we-selvooil mpompo	11 kw
2	I-Servo Pump Pumplement	80 l / min
3	I-Blowprestrure	0.8 MPA
4	Ukusetshenziswa komoya komoya	0.7 M² / MI
5	Ukupholisa Ukucindezela Kwamanzi	0.3 MPA
6	Ukusetshenziswa kwamanzi	70 l / min
7	Isilinganiso sokusetshenziswa kwamandla	27 kWWS 37th
Iyunithi ye-extruder
1	Isikulufa ububanzi	2 * 70 mm
2	Isikulufa l / d ratio	24 l / d
3	Ukuncibilika kwe-capacit ye-HDPE	120 KG / HR -140 kg / hr
4	Inani lendawo yokushisa	4 Zone
5	Isikulufa sokushisa amandla	15.6 kw
6	Isikulufa FANPPOWER	0.5 kw
7	Amandla wemoto extruder	2 * 22 kw
Die ikhanda
1	Inani lezingxenye zokushisa	5 Zone
2	Ukushisa Amandla	22.8 kw
3	Ububanzi be-MaxDie-Pin	220 mm
4	Umthamo we-Accumulator	5 l
5	(Pe) isisindo se-accumulator	3.75 kg

Izici nezinzuzo

Le modeli ukuvulwa nokuvala okulungisiwe nokuvala isikhunta, kusetshenziswa i-Double Rood Rod Synchrous Meding Mechanism, kanye nengcindezelo eqondile yamafutha ekhiya isikhunta
Isitoreji isilinda die series
IVolumu ephezulu 30L
Amathini afanelekile Jerryrry, ama-Industrial Toolbox, kanye namathangi kaphethiloli, njll.
Isici esihlukile ukuthi silawulwa uhlelo lwe-hydraulic servo ukufezekisa impendulo yesenzo esisheshayo kanye nokusebenza kwamandla okuphezulu.

Izindawo zohlelo lokusebenza

Ibhokisi lamathuluzi, Jerrycan, umgqomo wesitaki

Umthandi

1. Malini imodeli yokuqongelela imodeli yokubumba?

Ngenxa yokwehluka komkhiqizo, umshini ungaba ne-robot arm / blowing engezansi uhlelo / idivaysi yesistimu, njll. Sicela wabelane ngokucaciswa komkhiqizo wakho, khona-ke thina hlinzeka ngesisombululo senkomba.

2. Ngingayikhetha kanjani imodeli efanele?

Amabhodlela ajwayelekile / ama-barnels njll. Amaphakheji, vele uqinisekise ivolumu le-max ye umshini. Kweminye imikhiqizo ekhethekile, isidingo cabanga nge platen / ukukhishwa / Amandla njll, sicela uxhumane nathi ukuze uthole ikhambi elifanele.

3. Qhathanisa nolunye uhlobo lomkhiqizo, kungani ngikhetha umshini wokubumba we-Kisole?

I-Kingle yathuthumela ngokubumba okushaya kusukela ngo-2008, okuhlangenwe nakho kwethu kungasekela okusha amakhasimende ukusungula ngokushesha imigqa yokukhiqiza futhi afinyelele utshalomali iyabuya. Eminyakeni engama-20 edlule, sithuthukile ngokuqhubekayo futhi sakhiwe ngokuzimela, ukuzuza ukukhiqizwa okuzinzile nokusebenzayo.

4. Yini isiqinisekiso sakho sekhwalithi yomshini?

Sizoba imishini yokuhlola ephezulu kakhulu ngaphambi kokulethwa ukuze uqiniseke ukuthi ukukhiqizwa kuzinzile. Futhi ahlinzeke iwaranti yeminyaka engu-1 selokhu kwafika umshini ifektri yakho. Uma kudingeka, futhi kunganikeza isitifiketi se-SGS.

5. Ngabe uhlinzeka ngokuqeqeshwa njalo kokulungiswa noma ukuxilongwa okukude kwephutha?

Yebo, asinawo amafayela wokulungiselela kuphela kepha futhi sibe nemibhalo yobuchwepheshe / Amavidiyo wokuxazulula izinkinga.
Uhlelo lomshini lunohlelo lwe-alamu, olungasiza kude Izinkinga Zokuxazulula Izinkinga

6. Iyini insizakalo yakho yokuthengisa ngemuva kokuthengisa?

Singathumela unjiniyela efektri yakho ukukusiza ukufaka nokuqeqesha, okuyinhloko izakhi ziza nesikhathi se-1-2 sewaranti yesikhathi, nezingxenye ezintekenteke zingaba ithathelwe indawo mahhala kungakapheli unyaka owodwa.
