Umshini wokwenza itafula lepulasitiki engu-183

Model:KGS120Z

I-Kinggle KGS120Z iyi-cutting-odge umshini wokwenza itafula lepulasitiki enzelwe izinhlelo zokusebenza eziyindilinga zokubumba. Ihlangabezana ngokugcwele itafula lepulasitiki noma ipulasitiki yokukhishwa kweplasitiki blow yokuhlanganisa umshini wokuhlanganisa, inikeza amadizayini abekwe ngokwezifiso nekhwalithi ephezulu, ikunikeza umphetho wokuncintisana.

IVolumu: 1000lIsisindo: 38t

Thumela Uphenyo

Incazelo Yomkhiqizo

I-KGS120Z 183 Plastic Table Ukwenza Umshini Wokulwa KwePest Panel Type Product, enjalo njengeThebula / i-Ware House njll. Umshini wokubumba owenziwe ngokwezifiso ungahle uphelele Hlangana nalezo zidingo ezikhethekile zokukhiqiza umkhiqizo, ngejubane eliphezulu ukukhiqiza ukusindisa izindleko zeyunithi.
Kubandakanya isilawuli sogqinsi se-MOOG 100, ingalo yerobhothi, nangaphansi Uhlelo lokushaya, ukuthuthukisa umkhiqizo kanye nekhwalithi.

Ukucacisa

inombolo yomkhiqizo	I-Material HDPE ...	Isilinda ka-Mold Ukuvala uwoyela (isilinda esisodwa)
inombolo yomkhiqizo	I-Material HDPE ...	Imodeli yomshini: kgs120z
Ukucacisa
1	Umthamo we-MAX	1000 l
2	Okukhiphayo (umjikelezo owomile)	I-300 PC / hr
3	I-Machine Dimension (l × w × h × h)	8.3 m × 6.8 m
4	Isisindo somshini	38 t
I-Clamping Unit
1	Amandla eCembang	1200 kn
2	Usayizi we-Mold Platen (w × h)	1300 mm × 1900 mm
3	Amapuleti okuvula ngaphandle kwempondo	I-600 mm-1600 mm
4	Unhlangothi oluhamba kancane	I-700 mm
5	Ubukhulu be-Max Mold (w × h)	I-1000 mm × 2000 mm
6	Ubukhulu bokubumba	I-630 mm - 830 mm
Ubuqhwaga
1	Amandla we-selvooil mpompo	25 kw
2	I-Servo Pump Pumplement	200 l / min
3	I-Blowprestrure	0.8 MPA
4	Ukusetshenziswa komoya komoya	2 m² / mi
5	Ukupholisa Ukucindezela Kwamanzi	0.3 MPA
6	Ukusetshenziswa kwamanzi	120 l / min
7	Isilinganiso sokusetshenziswa kwamandla	110 kW -130 kw
Iyunithi ye-extruder
1	Isikulufa ububanzi	I-120 mm
2	Isikulufa l / d ratio	30 l / d
3	Ukuncibilika kwe-capacit ye-HDPE	I-350 kg / hr
4	Inani lendawo yokushisa	6 Zone
5	Isikulufa sokushisa amandla	32.5 kw
6	Isikulufa FANPPOWER	0.6 kw
7	Amandla wemoto extruder	90 kw
Die ikhanda
1	Inani lezingxenye zokushisa	5 Zone
2	Ukushisa Amandla	38.8 kw
3	Ububanzi be-MaxDie-Pin	700 (800) mm
4	Umthamo we-Accumulator	25 (30) l
5	(Pe) isisindo se-accumulator	18(22) KG

Izici nezinzuzo

Isetshenziselwe ukukhiqiza imikhiqizo emikhakheni ehlukahlukene. Noma ngabe iziqukathi ezinkulu zokugqwala ezivinjezelwa embonini yamakhemikhali, emabhodleleni angenawo amazinga aqinile wokuhlanzeka embonini yezidlo, noma emabhokisini apakisha avela emikhiqizweni yansuku zonke yamakhemikhali, kungalawulwa ngokunembile ukuze kuhlangane nezidingo ezihlukahlukene zemakethe.
Inqubo yokudla yamukele ubuchwepheshe obunqenqemeni futhi ilungiselelwe ngokususelwa kwizici zokukhiqizwa kwamandla aphezulu komshini wokubumba we-120Z. Lawula ngokunembile isilinganiso sokugeleza kanye nokusatshalaliswa kwezinto ezivuthiwe ukuqinisekisa ubukhulu bodonga olufanayo ngesikhathi sokubumba imikhiqizo yevolumu enkulu ye-Ultra, nokuqeda amandla ekhwalithi yomkhiqizo, bese kuqeda amandla ekhwalithi okubangelwa ukondliwa okungalingani.
