I-10l inqola umshini wokubumba ovuthayo

Model:KGB70A

I-KGB70A iyinhlangano eguquguqukayo eyi-10l eqongelela umshini wokubumba owenzelwe ukubumba amabhodlela ama-max ayi-15. Njengomenzi womshini wamabhodlela wamanzi oholayo, sinikezela ngezixazululo ezenziwe ngezifiso zokuhlangabezana nezidingo zekhasimende. Umshini awugcini kumabhodlela amanzi kuphela, iziqukathi zokubulala izinambuzane, kanye nokukhiqizwa kwansuku zonke kwamakhemikhali amakhemikhali, kepha futhi nemikhiqizo emincane kodwa ekhethekile yokwakheka. Lo mshini uhlangabezana nezidingo ezahlukahlukene.

IVolumu: 20lIsisindo: 7.8T

Thumela Uphenyo

Incazelo Yomkhiqizo Specification Application

I-KGB70A 10L Iqongelela Umshini Wokubumba Wokuvuselela Ukuvulwa Okuhleliwe nokuvala imodeli, ekwamukela i-Double Dons Rod ukuvumelanisa mechanism, uwoyela I-Cylinder Direct Pressure Locking Lock, Isilinda se-Accumulator Die Go Head Serse. I-Hydralic Servo Syste Control, isivinini sokuphendula okusheshayo kanye nokusindisa kwamandla.
I-Suite engaphezulu yalowo mkhiqizo okhethekile wokwakha umkhiqizo wokwakha, angakwazi Lawula ukwakheka nobukhulu ukunemba okwengeziwe.

Izici nezinzuzo

Le modeli ukuvulwa nokuvala okulungisiwe nokuvala isikhunta, kusetshenziswa i-Double Rood Rod Synchrous Meding Mechanism, kanye nengcindezelo eqondile yamafutha ekhiya isikhunta
● Isitoreji isilinda die uchungechunge lwekhanda
● IVolumu ephezulu ye-20L
● Ilungele amabhodlela amanzi, iziqukathi zokubulala izinambuzane, kanye nokupakishwa kwansuku zonke kwamakhemikhali, njll.
● Isici esihlukile ukuthi silawulwa uhlelo lwe-hydraulic servo ukufezekisa impendulo yesenzo esisheshayo kanye nokusebenza kwamandla okuphezulu.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
