I-30l Jerry ingakwazi ukukhishwa kwesiteshi esisodwa somshini wokubumba

Model:KGH30L

Supercharge ukukhiqizwa kwakho okupakisha nge-KGH30L 30L Jerry kungaba rversing ukukhishwa kwesiteshi sokubumba isiteshi sokubumba, i-30L jerry ingabangelisa umshini wokubumba izicelo zokubumba ama-20liter Drum Machine application! Isitayela se-Arm esigoqiwe se-cling curn ukuhlinzeka ngamandla aphakathi nendawo, ilungele umshini wokubumba welitha ayi-18 idinga imishini engama-20l kanye neJerrycans, kukusiza ukuthi unqobe imakethe ngekhwalithi ephezulu.

IVolumu: 30lIsisindo: 22.5t

Thumela Uphenyo

Incazelo Yomkhiqizo Specification Application

Supercharge ukukhiqizwa kwakho kokupakisha ne-KGH30L, i-Ultimate 30l Jerry ingashayela isitebhisi esiseduze kwesiteshi sokuhlanganisa esibeka indinganiso entsha ye-20l Izicelo ze-DRUM. Okubandakanya idivaysi ye-arm-turem egobile ye-arm, lokhu Umshini uqinisekisa amandla kakhudlwana aze athumele, ukuletha imiphumela engenaphutha njalo isikhathi. Ilungele ngokuphelele i-18l kuya ku-20l Drums kanye namathini kaJerry, i-KGH30L ihlanganisa ukusebenza kahle ngekhwalithi ephezulu ye-tier ukukusiza ekubuseni imakethe. Yakhelwe ukunemba nokuqina, lo mshini ulungile Isixazululo samabhizinisi afuna ukuphakamisa amandla abo okukhiqiza futhi khiqiza imikhiqizo yokufaka e-premium.

Izici nezinzuzo

Khulisa ukukhiqizwa kwakho ngomshini wethu wesiteshi esisodwa oqhubekayo wokuvuselela umshini wokubumba, owenzelwe iziqukathi ezifika ku-30l. Ngokucushwa okuguquguqukayo (2, 3, noma ama-4 amakhanda anhlobonhlobo amakhanda anhlobonhlobo), kusiza uhla olubanzi lwamabhodlela ezitsha, kusuka emabhodleleni amancane kuya ezitsheni ezinkulu ezingama-30r nemigqomo ephumelelayo, ikhwalithi esebenzayo.
Ilungele izinhlelo zokusebenza ezifana ne-shampoo, ukuquleka kwezingubo zokuhlanza, kanye nokupakishwa kwezimonyo, lo mshini uletha ukukhiqizwa okuphezulu ngenkathi ugcina ikhwalithi ephezulu. Ukusebenza kwayo okuhlukahlukene nosizo olusebenzayo lunciphisa imfucuza nokukhulisa okukhishwayo, okwenza kube yisixazululo esisebenza ngemali esikhulisa ukubuya kwakho ekutshalweni kwemali.

Specifications

serial number	Material PE、PP、PVC、PA...	High speed movement mode(curved arm)
serial number	Material PE、PP、PVC、PA...	Machine model:KGH30L
Specifications
1	Max container capacity	30 L
2	Output(dry Cycle)	450 PC/HR
3	Machine Dimension(L×W×H)	4.8 M x 2.1 M x 3.5 M
4	Machine weight	22.5T
Clamping Unit
1	Clamping force	300 KN
2	Mold platen size(W×H)	630 MM x 680 MM
3	Platen openingstroke	450 MM -1000 MM
4	Platen moving stroke	750MM
5	Max mold size(W×H)	730 MM - 680 MM
6	Mold thickness	480 MM - 580 MM
Power
1	Servooil pump motor power	22 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	1.8 M³/MIN
5	Cooling water pressure	0.2 Mpa - 0.3 Mpa
6	Water consumption	180 L/min
7	Average energy consumption	70 KW -80 KW
Extruder unit
1	Screw diameter	90 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	180 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	16 KW
6	Screw fanpower	0.9 KW
7	Extruder motor power	75 KW
Die head
1	Number of heating sections	3 * 8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	Accumulator capacity	280 MM
5	(PE)Accumulator weight	170 MM
