Isivinini esiphezulu se-15l esiteshini esisodwa sokuvumba umshini wokubumba

Model:KGH15L

Vula amandla akho okukhiqiza nge-KGH15L Speed High Speed 15l Isiteshi esisodwa Sokubumba Umshini wokubumba, ungazikhethela inhloko e-Multi-Die ngomshini wokubumba ama-5l Blow wokubumba, lokho kusebenza kahle kwezicelo zomshini weplastiki! I-curved arm isitayela se-clingting divayisi ukuhlinzeka ngamandla aphezulu wokuhlanganisa amandla, yenza i-bhedle / i-barter yalo.

IVolumu: 15lIsisindo: 7.5T

Thumela Uphenyo

Incazelo Yomkhiqizo

Isivinini esiphezulu se-KGH15L esiteshini esiphezulu se-15l Blow Blow Solding Machine akuyona nje umshini, kepha umlingani onamasu wamabhizinisi ngifuna ukuthuthukela ekukhiqizeni okukhaliphile. Ukwakhiwa kwalo modular Ukunwetshwa kwesikhathi esizayo kanye nokuthuthuka, okwenza kuhambisane namamojula we-automation njengokususwa kwengxenye ezenzakalelayo nokuhlolwa kwe-inthanethi, ukusiza amafektri maqondana nezimboni 4.0.

Ukucacisa

Inombolo yomkhiqizo	Indwangu PE, PP, PVC, PA ...	Uchungechunge olunyakazayo
Inombolo yomkhiqizo	Indwangu PE, PP, PVC, PA ...	Imodeli Yomshini: KGH15L
Ukucacisa
1	Umthamo we-MAX	15 l
2	Okukhiphayo (umjikelezo owomile)	I-450 PC / hr
3	I-Machine Dimension (l × w × h × h)	4.5 m x 2.2 m x 2.8 m
4	Isisindo somshini	7.5 t
I-Clamping Unit
1	Amandla eCembang	165 kn
2	Usayizi we-Mold Platen (w × h)	500 mm x 550 mm
3	Amapuleti okuvula ngaphandle kwempondo	I-280 mm -680 mm
4	Unhlangothi oluhamba kancane	I-600 mm
5	Ubukhulu be-Max Mold (w × h)	580 mm x 500 mm
6	Ubukhulu bokubumba	I-300 mm - 380 mm
Ubuqhwaga
1	Amandla we-selvooil mpompo	18.5 kw
2	I-Servo Pump Pumplement	130 l / min
3	I-Blowprestrure	0.6 MPA
4	Ukusetshenziswa komoya komoya	0.8 m³ / min
5	Ukupholisa Ukucindezela Kwamanzi	0.2 MPA - 0.3 MPA
6	Ukusetshenziswa kwamanzi	70 l / min
7	Isilinganiso sokusetshenziswa kwamandla	25-34 kw
Iyunithi ye-extruder
1	Isikulufa ububanzi	75 mm
2	Isikulufa l / d ratio	25 l / d
3	Ukuncibilika kwe-capacit ye-HDPE	I-100 kg / hr
4	Inani lendawo yokushisa	4 Zone
5	Isikulufa sokushisa amandla	16 kw
6	Isikulufa FANPPOWER	0.6 kw
7	Amandla wemoto extruder	30 kw
Die ikhanda
1	Inani lezingxenye zokushisa	3 * 8 Zone
2	Ukushisa Amandla	6.5 kw
3	Ububanzi be-MaxDie-Pin	220 mm
4	Umthamo we-Accumulator	240 mm - 280 mm
5	(Pe) isisindo se-accumulator	150 mm

Izici nezinzuzo

Umshini wokubumba owodwa oqhubekayo oqhubekayo oqhubekayo wenzelwe ukukhiqizwa okuphezulu kwevolumu, enikeza ukuguquguquka nokusebenza kahle kweziqukathi kuze kube ngu-15l. Idizayini yayo entsha ivumela ukushintshwa okulula phakathi kokucushwa kwekhanda okukodwa nokwe-dil-die, ukuqinisekisa ukusebenza kahle kosayizi abahlukahlukene.
Lo mshini uvelele ukusebenza kwawo okuphezulu, unika amandla ukuguqulwa okusheshayo phakathi kokucushwa ukukhulisa okuphumayo futhi kunciphise isikhathi sokuphumula. Futhi kuguquguqukayo, okwazi ukukhiqiza iziqukathi ezahlukahlukene ezivela kumabhodlela e-shampoo eJerrycans, okwenza kube kuhle kwizimboni ezahlukahlukene.
Ngekhwalithi ephezulu, iqinisekisa ukukhiqizwa okungaguquki ngokunemba, ukuhlangabezana namazinga aphezulu kakhulu. Ngokwengeziwe, umklamo wawo ongabizi anciphisa izindleko zokusebenza ngenkathi wenza ngcono umkhiqizo. Yakhelwe ukuthembeka, umshini wenza ngokuqhubekayo ngemiphumela ezinzile, noma ngaphansi kwezimo ezifunwa kakhulu.
Phakamisa amakhono akho okukhiqiza nalo mshini wokubumba onamandla futhi ovumelanisa nezimo eziguqukayo oletha ikhwalithi nokusebenza kahle.
